Class 100 Vertical Laminar Flow Cabinet LAF Hood CHINA(JH-LF1320)


Model: JH-LF1320

This double-person single-side (vertical air supply) clean bench  is widely used in medicine,

pharmacy,biological & chemical experiment, electron, precise apparatus,instrument and so on.

Characteristics
1. Vertical manifold and quasi-closed 304 stainless steel table surface can effectively prevent external gas
penetration into the operating clean area.
2. Centrifugal fan, stable speed, low noise, light touch air volume control system, five-stage wind speed
control, speed 0.2-0.6m/s adjustable, (initial: 0.6m/s; Final:0.2m/s).
3. High quality air filter without partition, good purification effect.
4. LCD color screen controller (with sterilization timer, built-in socket instrument con-trollable switch,
front window status display, can set three interlock , cumulative work timing, remote control).
3. Wind speed sensor.
4. Automatic cutting off UV lamp function by opening glass.



Main Technical Parameters:

Model JH-LF920 JH-LF1320
Applicable Station one person one side/one operator two side two person one side/two person two side
Cleanliness Class 100
Collection Efficiency 0.3um partical >99.995%
Colony count <0.5  /vessel( petri dish is ф 90mm )
Wind Speed initial: 0.6; final: 0.2 ( m/s )
Wind Speed Range 0.2-0.6 ( m/s )
Work Surface 50kg
Inner Chamber SUS304 Stainless steel plate
Outer Shell Cold rolling steel electrostatic spraying exterior
Operation Door Tempered Glass
HEPA filter ( mm ) 900*640*50 one piece 1300*640*50 one piece
Pre-Filter 464*360*5 one piece 712*360*5 one piece
Fluorescent Lamp 16W*2 24W*2
UV Lamp 20W*1 30W*1
Top Fan 180W one piece 180W two pieces
Rated Power 240W 440W
Display LCD color screen
Wind Speed Control Intelligent multi-level adjustable
Additional Function Built in 2 multi-purpose sockets, high-efficiency filter, sterilization lamp replacement prompt, foot level adjustment, lighting sterilization one key on/off
Inner Size ( W*L*H )mm 920*690*650 920*690*650 1320*690*650 1320*690*650
Exterior Size (W*L*H )mm 1060*763*1834 1060*763*1834 1460*763*1834 1460*763*1834
Packing Size ( W*L*H ) mm 1210*885*1999 1210*885*1999 1610*885*1999 1610*885*1999
